Schneider Electric CONEXT XW Mini Power Distribution Panel

MSRP: $1,013.00
— You save $295.01


The XW Power Distribution Panels (XW PDP and Mini PDP) are factory-wired and labeled to support the integration of multiple XW series inverter/chargers and Conext MPPT Solar Charge Controllers with a single battery bank. The XW PDP and Mini PDP ships with breakers, bus bars and cables to install a single XW series inverter/charger. With space to add wiring and breakers, a single XW PDP and Mini PDP supports one XW series inverter/charger, a diesel generator and either an MPPT 100 600, MPPT 80 600 or MPPT 60 150 Solar Charge Controller. The XW PDP and Mini PDP support single-phase, split-phase or three-phase installations. A field-reversible door and multiple conduit knockout entry points allow for the XW PDP and Mini PDP enclosure to be mounted and configured on either side of the inverter/charger.

XW Power Distribution Panels help you save significant time and money during installation when compared to custom solutions. A mounting bracket and XW Conduit Box are also supplied with each XW PDP and Mini PDP.

The XW Mini Power Distribution Panel (Mini PDP) provides a compact, easy to install DC and AC power distribution cabinet compatible with the Conext XW series inverters. The Mini PDP can be used for managing power distribution to the XW inverter, MPPT Charge Controllers, the battery, and a generator.


The PDP is designed for compact installation below the XW inverter and easy installation:

Includes a main 250 A DC breaker for the battery
Includes AC breakers for AC input, Bypass, and AC Out (load)
Breaker expansion positions on DC side for solar charge controllers and AC side for generator or AC coupled PV inverter
AC wiring and DC bus bars for direct connection to the XW inverter
Split phase, single phase applications
Mounts below the XW inverter
Multiple conduit knockouts and a field reversable door
Compatible with Conext MPPT charge controllers, and includes mounting provisions for MPPT 60 150 Charge Controllers on the either side
Saves installation time with a pre-wired solution


  • Manufacturer: Schneider Electric
    Product Line: Power Distribution Panel
    Model ID: 865-1013-01
