Schneider Electric CONEXT XW+ And SW Configuration Commissioning Software-PC Tool
- SKU:
- 865-1155-01
Everything you need to go solar, all in one kit.
Spec out a full parts list for your solar project. We'll help design a complete system to meet your project goals.
Questions? We’re Here to Help.
Get timely, human assistance from people with real-world experience. No question is too large or too small - reach out to us for guidance.
We're open M-F, 6am-4pm PST. After-hours messages get a response within 1 business day.
Description
The Conext™ Configuration tool is a PC-based software used by system installers to calibrate multi-unit systems during system configuration and reduce installation time.
The Conext Configuration tool is not meant to replace the Insight or any other monitoring devices. Those monitoring devices may still be required to monitor Schneider Electric solar and storage system and components.
Software and drivers for the Conext Configuration Tool are under the downloads section (Firmware).
Conext Config USB Driver is firmware used for general installation setup.
Conext Config Tool Software_AI (Anti-Islanding) is used when 2 or more inverters are installed in parallel on a single phase connection (See Conext XW+ Multi-Unit Power System Design Guide under the downloads section (Technical Publications). It is also used if there is a specific requirement by a utility.
Note: Adjustment of AC anti-islanding parameters should only be done after consultation with the power utility or authority having jurisdiction.
Features
The Configuration Tool allows the installer to perform the following functions:
System and device configuration
System logging
Firmware upgrades
Saving and Restoring configurations
Single inverter or multi-cluster configuration
Parameter adjustment, Voltage and Frequency
Compatible OS : Windows 7 , 8 and 10
Specifications
-
Manufacturer: Schneider Electric
Product Line: Configuration Tool
Model ID: 865-1155-01
