Rich Solar 30 Amp PWM Solar Charge Controller

Specifications

• Manufacturer: Rich Solar
  Product Line: Charge Controller
  Model ID: RS-PWM30K

• PV voltage: ≤50V
• Rated Current: 30A
• System Voltage: 12V/24V Auto
• HVD: 16.00V×1/×2/×3/×4(0.5V)
• Rated discharging current: 30A
• No-load loss: ≤13mA
• Charge loop voltage drop: ≤0.24V
• Discharge loop voltage drop: ≤ 0.1V
• Charging mode: PWM 4-stage（bulk, absorption, float, equalized）
• Voltage of float charging: 13.8(13V~15V)×1/×2
• Voltage of absorption charging: 14.4V(13V~15V) ×1/×2
• Voltage of equalized charging: 14.6V(13V~15.5V) ×1/×2
• Duration of equalized charging: 2hs
• LVD: 10.7V(10V~14V) ×1/×2
• LVR: 12.6V(10V~14V) ×1/×2
• Load working mode: Regular control mode, Light control with switch-off point at night and switch-on point before dawn, Light control mode
• Light control voltage: 5V(1V~10V) ×1/×2
• Battery type: GEL, SLD, FLD and USR (default)
• USB: 5V 1A
• Wiring: PCB terminal, ≤16mm2
• Working temperature: -20 ~ +55 °C
