Renogy
Renogy 100 Watt 12 Volt Solar Starter Kit with 40A MPPT Charge Controller
- SKU:
- RNG-KIT-STARTER100D-RVR40-US
- SHIPPING:
- FREE Shipping! (Estimated delivery 5-7 business days)
Description
Renogy 100 Watt 12 Volt Solar Starter Kit with 40A MPPT Charge Controller
With a Renogy 100W Monocrystalline Starter Kit MPPT, you won't have to wonder about whether or not you're getting the most out of your system. Designed to draw out your system's potential, this kit includes our 40A MPPT charge controller which uses Maximum Power Point Tracking technology, transferring power up to 30% more efficiently than PWM charge controllers.
Geared towards providing you with the most efficient system possible, the Renogy Starter Kit MPPT could be the perfect fit for you.
KEY FEATURES:
Efficient- High solar cell efficiency: Monocrystalline 18.4%
- Bypass diodes minimize power drop caused by shade and ensure excellent performance in low-light environments
- The included MPPT charge controller has a peak efficiency of 97%
- EL tested solar modules; no hot-spot heating guaranteed
- Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades
- TPT back sheet ensures smooth performance over a long period of time
- IP65 rated junction box provides complete protection against environmental particles and low pressure water jets
- Sealed, Gel and Flooded charging algorithim ready
- 4-Stage battery charging process for a rapid, efficient, and safe battery charging
- Timer function with 1-15 hour option
- The Renogy 40A MPPT is equipped with multiple electronic protections; overcharging, overload, short-circuit and reversed polarity
- Pre-drilled holes on the back of the panel allow for fast and secure mounting
- With a Renogy 40A MPPT Charge Controller, you can expand your system up to a maximum of 400W (12 Volt) or 800W (24 Volt)
- The Renogy 100W Monocrystalline Expansion Kit is the perfect solution for future expansion
Please note:When you add panels to your system, you will need one set of Z brackets for each additional panel. You will also need one pair of branch connectors to expand your system to 600W or 800W
PACKAGE INCLUDES
Renogy 100 Watt 12 Volt Monocrystalline Solar Panel (Compact Design)
Rover 40A MPPT Charge Controller
Mounting Z Brackets
Renogy 20ft 10AWG MC4 Adaptor Kit (A pair)
Renogy 8ft 8AWG Tray Cables (A pair)
Solar Y Branch Connectors MMF+FFM Pair
Specifications
Maximum Power: 100W
Maximum System Voltage: 600V DC (UL)
Open-Circuit Voltage (Voc): 24.3V
Short-Circuit Current (Isc): 5.21A
Optimum Operating Voltage (Vmp): 20.4V
Optimum Operating Current (Imp): 4.91A
Weight: 14.1 lb (6.4 kg)
Dimensions: 41.8 x 20.9 x 1.4 in (1062 x 530 x 35 mm)
Rated Battery Current :40A: 12V/24V Auto Recognition
Max. Battery Voltage: 32V
Rated Load Current: 10% to 90% NC
Max Solar Input Voltage: 100VDC
Working Temperature: -31°F to 113°F
Max Terminal Size: 8AWG
Max. PV Input Power: 12V/520W, 24V/1040W
Max Battery Voltage: 32V
Weight: 4.41lb
Dimension: 9.37 x 6.81 x 2.85 in
Length: 20ft
AWG: 10
Rating Voltage: 600/1000V
Temperature: -40°F to +185°F
Length: 8ft
AWG: 8
Rating Voltage: 600/1000V
Temperature: -40°F to +185°F
Eight Long Cap Bolts and Four Short Bolts: Four Spring Washers and Four Washers
Four Z Shape Solar Panel Brackets: Four Nuts
Withstanding voltage: 1000V DC(TUV), 600V(UL)
Rated Current: 50A
Protection Degree: IP67, mated
Protection Class: Class II
Temperature: -40°F to +194°F
Panels: 25-year power output warranty: 5 year/95% efficiency rate, 10 year/90% efficiency rate, 25-year/80% efficiency rate 5-year material and workmanship warranty
Accessories: 1-year material warranty
