Enphase X-IQ-AM1-240-6C-3BRK IQ Combiner 6C with IQ Gateway & 3 Pre-Installed Breakers

The IQ Combiner 6C has an integrated gateway, breaker spaces for IQ PV, IQ Battery, IQ EV Charger, and controlled loads. It includes integrated CTs for PV/Battery metering, a cell modem with data pack, 2x 20A PV + 1x 40A Battery breakers.

The IQ Combiner 6C consolidates interconnection equipment into a single enclosure, streamlining the installation of IQ Series Microinverters. It integrates the IQ Gateway to offer a consistent, pre-wired solution for residential applications. It includes breaker spaces for PV, battery, EV charger, and an integrated load controller. Additionally, it reduces installation time with integrated and pre-wired current transformers for PV and batteries.

Features

Smart
• Integrated combiner controller board (CCB) and IQ Gateway.
• Includes Enphase Mobile Connect (CELLMODEM-07-NA).
• Supports flexible networking: Wi-Fi, Ethernet, or cellular.
• Integrated revenue-grade production and storage metering via pre-installed current transformers. Also supports consumption and EV chargermonitoring.

Easy
• Pre-installed UL 489 certified device for Rapid Shutdown.
• Single-stud mountable with two screws.
• Supports multiple conduit entry options such as top side right, top side left, bottom side left, bottom side right, bottom rear, and bottom.
• Supports up to five PV branches, two battery circuit breakers and one EVSE circuit breaker.
• Bluetooth-based Wi-Fi provisioning for easy Wi-Fi setup.
• Supports an integrated load controller with up to 80 A using double-pole or quadplex breakers.

Reliable
• Durable NRTL-certified NEMA type 3R enclosure.
• 15-year limited warranty.
