EG4 EG4INVFLXBOSS18V1 FlexBOSS18 24.0kW Hybrid Inverter

EG4, FlexBOSS18, 13kW AC Hybrid Inverter, 18kW PV Input, 13kW On-Grid AC Output, 60Hz, 48VDC, 120-240Vac Split-Phase, Transformerless Sine Wave, 2 MPPT PV Inputs, 600VDC Max, Built-In RSD, NEMA 4X, 10 Year Warranty, EG4INVFLXBOSS18V1

The EG4® FlexBOSS18 is a 13kW, 120/240VAC split-phase, all-in-one hybrid sine wave inverter, designed for residential and small commercial applications. It supports up to 18kW (STC) of solar PV input across two MPPTs (26A each) and can deliver 10kW of continuous power from the battery or 13kW with solar PV assistance when grid-connected. The FlexBOSS18 also features a 90A grid bypass capability, allowing seamless power flow from the grid to connected loads.

As the more affordable, entry-level counterpart to the FlexBOSS21, the FlexBOSS18 offers a powerful solution for energy independence. While fully capable as a standalone inverter, it is optimized for use with EG4’s GridBOSS power gateway, unlocking enhanced functionality and performance for the end user.

Features

All-In-One Hybrid Inverter
Capable of Running Entirely Off Grid, Using Grid Electricity, and Selling Power Back to The Grid.

Up to 600 VDC Input
The Extra High Voltage Enables Lower Cable Sizing for The 2 Mpp Ts and A Maximum Recommended Pv Input of 18k W, Eliminating the Need for A Combiner Box.

Plug-In Wi-Fi Device
Enables Wireless Connection Between Our Monitoring Platform and The Flex Boss18 Through the Eg4® App or Eg4 Monitor System for Remote System Management.

Closed-Loop Communications
Able to Communicate with Eg4 48 v Batteries and Other Battery Brands. a Battery Firmware Update Is Required for Closed-Loop Communications with Life Power4 V1 Batteries.

Rapid Shutdown
The Flex Boss18 Is Csa C22.2#330:2017 and Nec 690.12 Ready with Its Built-In RSD Capabilities.
