Enphase

Enphase IQ Combiner 4C (IEEE certified) 1547:2018 Compliant IQ Gateway, Max 80A and 4 AC Branch Circuits

SKU:
X2-IQ-AM1-240-4C
SHIPPING:
FREE Shipping! (Estimated Arrival: 5-10 business days)
  • Enphase IQ Combiner 4C (IEEE certified) 1547:2018 Compliant IQ Gateway, Max 80A and 4 AC Branch Circuits
  • Enphase IQ Combiner 4C (IEEE certified) 1547:2018 Compliant IQ Gateway, Max 80A and 4 AC Branch Circuits
  • Enphase IQ Combiner 4C (IEEE certified) 1547:2018 Compliant IQ Gateway, Max 80A and 4 AC Branch Circuits
$1,167.40

Description

The Enphase IQ Combiner 4/4C with IQ Gateway and integrated LTE-M1 cell modem (included only with IQ Combiner 4C) consolidates interconnection equipment into a single enclosure and streamlines Enphase Energy Systems by providing a consistent, pre-wired solution for residential applications. It offers up to four 2-pole input circuits and Eaton BR series busbar assembly. Compatible with IQ8 Microinverters.

  • Includes IQ Gateway for communication and control
  • Includes Enphase Mobile Connect cellular modem (CELLMODEM-M1-06-SP-05) with 5-year data plan provided by Sprint, included only with IQ Combiner 4C
  • Alternate Enphase Mobile Connect modem with 5-year data plan provided by AT&T (CELLMODEM-M1-06-AT-05) and Verizon (CELLMODEM-M1-06-VZ-05) available separately to be used with IQ Combiner 4
  • Includes solar shield to match Enphase IQ Battery aesthetics and deflect heat
  • Flexible networking supports Wi-Fi, Ethernet, or cellular
  • Optional AC receptacle available for PLC bridge
  • Provides production metering and consumption monitoring
  • Centered mounting brackets support single stud mounting
  • Supports bottom, back, and side conduit entry
  • Up to four 2-pole branch circuits for 240VAC plug-in breakers (not included) with hold down kit support
  • Durable NRTL-certified NEMA type 3R enclosure
  • Five-year limited warranty
  • Two years labor reimbursement program coverage included
  • Compatible with IQ8-Series and IQ7-Series Microinverters
  • UL listed
  • X2-IQ-AM1-240-4C complies with IEEE 1547:2018 (UL 1741-SB, 3rd Ed

What’s in the box:

  • IQ Combiner 4C
  • IQ Gateway PCBA
  • Pair of Consumption Current Transformers (CT)
  • Production Current Transformers (CT)
  • Solar shield
  • Mobile Connect Cell Modem

Specifications

  • x2-iq-am1-240-4.png
  • x2-iq-am1-240-4-2nd.png
