SunGoldPower

SunGoldPower 560 Watt Bifacial PERC Solar Panel

SKU:
SG560WBGx2
UPC:
747783675420
Availability:
Backordered until 7/15/25
SHIPPING:
FREE Shipping (Estimated Arrive 5-7 business days)
  • SunGoldPower 560 Watt Bifacial PERC Solar Panel
  • SunGoldPower 560 Watt Bifacial PERC Solar Panel
  • SunGoldPower 560 Watt Bifacial PERC Solar Panel
  • SunGoldPower 560 Watt Bifacial PERC Solar Panel
  • SunGoldPower 560 Watt Bifacial PERC Solar Panel
$982.30
In stock and ready to ship
Frequently bought together:

Everything you need to go solar, all in one kit.

Spec out a full parts list for your solar project. We'll help design a complete system to meet your project goals.

Design My Complete Kit
Read Our 1000+ Google Reviews
Support

Questions? We’re Here to Help.

Get timely, human assistance from people with real-world experience. No question is too large or too small - reach out to us for guidance.

We're open M-F, 6am-4pm PST. After-hours messages get a response within 1 business day.

Call us
Email us

Description



A+01.jpg__PID:0aee98a6-03e0-479a-b4c3-70261a99538d

Sungoldpower Bifacial solar panels are solar panels that can capture sunlight on both their front and back, it can generate up to 30% more energy than conventional solar panels, Bifacial solar panels are ideal for installations where the backside of the solar array is exposed and can capture reflected light, including ground-mount systems, solar carports and canopies.

Features

★Bifacial monocrystalline PERC solar panel can generate more energy up to 30%

★Bifacial modules offer higher durability even rough climatic heat /cold/snow/wind

★The space requirement for installation is less because of high efficiency

★It can be set up at any angle. no need to analyse or calculate the right mounting and tilt angle

★25 Years Performance warranty and 30% residential Clean Energy Credit

A+02.jpg__PID:ea55e818-5235-4fcd-80b7-ec26e6f85f9c
A+03.jpg__PID:067b86e6-57f7-41df-93a0-f7abbe8b0c13

Improved PV Module Performance under PartialShading Conditions

The panel features an innovative design of PERC, half-cut cells, bypass diodes and 11-busbar technology to maximize energy output even under partial shading.

A+05.jpg__PID:86e657f7-d1df-43a0-b7ab-be8b0c133860
A+04.jpg__PID:7b86e657-f7d1-4f93-a0f7-abbe8b0c1338
A+06.jpg__PID:63fe51c7-5b14-4c5f-895d-8e1d91a2fba6
A+07.jpg__PID:57f7d1df-93a0-47ab-be8b-0c133860fd12

Specifications

  • Manufacturer: SunGoldPower

    Product Line: Solar Panel

    Model ID: SG560WBG

Specifications

Model TypeSG560WBG
Peak Power (Pmax) 560W
Production tolerance ±3%
Maximum Power Current (Imp) 13.3A
Maximum Power Voltage (Vmp) 42.1V
Short Circuit Current (Isc) 14.09A
Open Circuit Voltage (Voc) 50.09V
Maximum System Voltage 1500V
Wind Resistance 2400Pa
Output Cables  12 AWG (1ft per cable)
Number of Cells  144(6x 24),60 cells in series
Cell Type PERC Monocrystalline (7.2x 3.6 in)
Certifications CE TUV
Product Weight 67.9lbs
Product Dimension 89.8*44.7*1.4inch
Package Weight 128.7lbs（2PCS）
Package Dimension 92.5*47.6*3.1inch（2PCS）
Performance 5 year 95% output warranty 10 year 90% output warranty 25 year80% output warranty
Material and workmanship warranty 10 year material and workmanship warranty

INFO & GUIDE

pdf.pngDownload 560 Watt Bifacial Solar Panel User Manual
View AllClose

Warranty Information

25 Years Performance warranty and 30% residential Clean Energy Credit. The solar panels come with 12-year Material and Workmanship Warranty, and 30-year Linear Performance Warranty.
