APsmart APSM-PLC-KIT-DC-408005 Dual Core Transmitter - PLC-Outdoor Kit IP65, 180-550VAC Power Supply

Dual Core Transmitter - PLC-Outdoor Kit IP65, 180-550VAC Power Supply

Raising the bar in innovative DC MLPE solar power systems.

The APsmart Rapid Shutdown System Transmitter-PLC is part of a rapid shutdown solution when paired with APsmart RSD-S-PLC, a PV module rapid shutdown unit. While powered on, the Transmitter-PLC sends a signal to the RSD-S-PLC units to keep their PV modules connected and supplying energy.

RSD-S-PLC units automatically enter rapid shutdown mode when the Transmitter-PLC is switched off and resume energy production when power is restored to the Transmitter-PLC. This solution complies with NEC 690.12 specifications for 2017&2020 and supports the SunSpec signaling for rapid shutdown.

Transmitter-PLC Outdoor Kit includes a Transmitter-PLC with one or two cores, outdoor enclosure, 85-264VAC or 180-550VAC power supply. It could be used in residential or commercial project.

Features

• Meets NEC 2017&2020 (690.12) requirements
• Switching off Transmitter-PLC results in rapid shutdown of the output of PV modules
• Meets SunSpec requirements
• Equipped with single/dual core
• Optional 85-264VAC power supply
• Optional 180-550VAC power supply
