Renogy 48V 3500W Solar Inverter Charger

Renogy's 3500W 48V Solar Inverter Charger combines solar charging, AC/generator battery charging, and battery inverting into one convenient solution to take your off-grid system to the hybrid level. Compatible with 48V battery banks, this solar inverter charger gives you the ultimate control with four user-configurable AC/Solar Charging modes and three Load Output modes that can turn your system into an uninterruptible power supply (UPS), automatically switching to Off-Grid Mode in just 10 milliseconds to keep loads securely powered.

Power-packed with the latest MPPT and battery charging technology, you can be sure that the charge controller captures maximum solar energy in real-time and uses the 120A battery charger to ensure the best system performance. This reliable, solar pure sine wave inverter charger has built-in electronic safeguards to protect you and your system. Equipped with multiple features and modes, the Renogy Solar Inverter Charger is a powerful addition to any 48V system!





48V 3500W Solar Inverter

Inverter Remote Control



Inverter Mode Specifications

Output Waveform: Pure Sine Wave

Continuous Output Power: 3500W

Peak Power Rating: 7000W

Output Voltage: 120VAC±5%

Output Frequency: 50 Hz ± 0.3% 60 Hz± 0.3%

Input Voltage / Rated Battery Voltage: 48VDC (minimum start-up voltage 44V)

Nominal Efficiency: > 90%

Bypass Breaker Current Load: 40A

Idle Consumption: 48W

Power Saver Mode Idle Consumption: <25W

Solar Charging Mode Specifications

Charge Controller Type: MPPT

Maximum Input Power: 4800W

Maximum Input Current: 50A

PV Charging Current Range: 0-80A

Recommended Max. PV Open Circuit Voltage: 145VDC

PV Operating Voltage: 60-145VDC

MPPT Voltage Range: 60-115VDC

Short-circuit Protection: Internal Fuse

Wiring Protection: Reverse Polarity

Recommended Wiring: 4 AWG

AC / Grid Charging Mode Specifications

Rated Input Voltage/Input Voltage Range: 120Vac/90 ~ 140VAC ± 2% Adjustable

Frenquency: 50 Hz / 60 Hz (auto detect)

Efficiency: >95%

Conversion Time: 10ms

Battery Type: Lead Acid and Lithium Battery

Maximum Charging Current: 40A

Charging Voltage Range: 40-60VDC

Short-circuit Protection: Breakers and fuses

Overcharge Protection: Yes. Automatically alerts and turns off charging after 1 min)

Reverse Flow Protection: Yes

Mechanical Specifications

Dimensions: 16.8*12.7*4.9 in / 426*322*124 mm

Weight: 23.8 lbs /10.8kg

Communication Port: RS485/CAN Communication Port (BT-2 Bluetooth Module)

Cooling Fan: Yes

Operating Temperature Range: 5°F ~ 131°F/ -15°C ~ 55°C

Storage Temperature: -13°F ~ 140°F / -25°C ~ 60°C

Humidity: 5% to 95% (three-layer paint protection)

Noise: ≤60dB

IP Grade: IP 20

Safety Class: I


Model: RMS-LP4-G2

Wireless Communication: Wi-Fi (IEEE 802.11b/g/n 2.4 GHz); Bluetooth 2.1/4.2 and Bluetooth LE; Zigbee (IEEE 802.15.4)

Touch Screen: 4 inches (480 x 480p) White backlight with adjustable brightness

Casing Material: PC+ABS V0

Operating Humidity: 0% to 95% RH

Power Supply: Rated Power 3.5W 1.Power Port: 8V DC-16V DC 2.Type-C Port: 5V DC

Ports: 1.USB Type-C (5V DC) 2.RJ45 (CAN & RS485) 3. 2-pin 2.54 mm pluggable terminal block (12V DC)

Color: Black

Weight: 286 g/0.83 lbs

Load: ≤30V DC, 5A Max

Power Consumption: < 2.5W (standby)

Installation:: Flush mounting

Operating Temperature: -20℃ to 50℃ (-4℉ to 122℉)

Operating Altitude: Less than 2000 m above sea level

Connection: Zigbee (IEEE 802.15.4)

Protocols: RV-C/Modbus/Zigbee 3.0

Dimension: 181.8 x 86.8 x 42.2 mm (7.16 x 3.42 x 1.66 in)

Applicable Place: Indoor


CE, FCC: Yes



Manufacturer: 2-year material and workmanship warranty
