Acudor
Acudor 18 x 18 High Security Steel Access Door SD-6000 with Heavy Duty Detention Lock
- SKU:
- SD-6000 18x18
- SHIPPING:
- FREE - Usually arrives in 7-10 days
Description
Acudor 12 x 12 SD-6000 Security Door
Application
- Installation ideal for prisons, correctional facilities, housing projects etc.
- Heavy duty access door designed for use in high security areas
Product Features
- 10 Gauge Door
- Security butt hinges are surface welded to the door and frame
- A detention type deadbolt lock with paracentric key is standard
SD-6000 Standard Sizes
NOMINAL DOOR SIZE W & H
|
WEIGHT PER DOOR
|
||
Inches
|
mm |
lbs.
|
kg.
|
12 x 12
|
305 x 305 | 22 |
10
|
16 x 16
|
406 x 406 | 30 |
13.8
|
18 x 18
|
457 x 457 | 46 | 21 |
24 x 24
|
610 x 610 | 70 |
31.8
|
24 x 36
|
610 x 914 | 90 |
41
|
36 x 36
|
914 x 914 | 120 |
54.4
|
Specifications
Specifications
Specifications
Material
|
Steel or Stainless Steel
|
Door / Mounting Frame
|
Mounting Frame: Door 10 gauge (.134) plate & frame is 2x2x3/16 angle, security to edge of frame. Mounting frame to have anchor straps
|
Hinge | Heavy duty butt hinges, welded to door and frame |
Standard Latch
|
Detention type deadbolt lock with paracentric key
|
Optional Latches/Locks
|
Tamperproof security cam latches, cylinder lock and key. When master keying is required, doors can be prepared for rim or mortise cylinder locks
|
Finish
|
5 stage iron phosphate preparation with prime coat of White alkyd baking enamel. Stainless Steel: #4 satin polish |
