Hanwha Q Cells Q.PEAK DUO XL G10.3 BFG 485W Mono Solar Panel

SKU:
Q.PEAK DUO XL G10.3 BFG 485W
Availability:
Ships LTL Freight Only
Minimum Purchase:
8 units
Unavailable
In stock and ready to ship

Description

Q CELLS 485W MONO SOLAR PANEL - Q.PEAK DUO XL G10.3 BFG 485W
Hanwha Q CELLS Q.PEAK DUO XL G10.3 BFG 485Watt 156 1/2 Cells Bifacial Double Glass Monocrystalline 35mm Silver Frame Solar Panel

This high-efficiency module is backed by Q Cells trademark Q.ANTUM cell technology, which is what powers their solar panels to produce a higher energy yield per surface area, lower BOS costs, higher power classes, and an efficiency rate of up to 21.4%.

Features

  • Technology - Higher yield per surface area, lower BOS costs, higher power classes, and an efficiency rate of up to 19.9%. Long-term yield security with Anti LID and Anti PID Technology, Hot-Spot Protect and Traceable Quality Tra.Q.
  • Performance - Optimal yields, whatever the weather with excellent low-light and temperature behavior. Long-term yield security with Anti LID and Anti PID Technology, Hot-Spot Protect and Traceable Quality Tra.Q.
  • Reliable - High-tech aluminum alloy frame, certified for high snow (5400 Pa) and wind loads (4000 Pa. Inclusive 12-year product warranty and 25-year linear performance guarantee.

Specifications

  • Manufacturer: Hanwha Q Cells
    Product Line: Q.PEAK DUO XL-G10.3/BFG
    Model ID: Q.PEAK DUO XL-G10.3/BFG 485W

  • Mechanical Data

    Technology: Monocrystalline (Mono)
    Dimensions:
    87.2 x 41.1 x 1.38 inches
    Weight: 64.2 lbs
    Front Cover: 0.08 in (2.0 mm) Thermally Pre-Stressed Glass with Anti-Reflection Technology
    Back Cover: 0.08in (2.0mm) semi-tempered glass
    Frame: Anodized Aluminum
    Cell: 6 × 26 monocrystalline Q.ANTUM solar half cells
    Connector: Staubli MC4; IP68

  • Electrical Data

    Power at MPP²: 485 Watts
    Short Circuit Current (Isc): 11.16 Amps
    Open Circuit Voltage (Voc): 53.63 Volts
    Current at MPP (Impp): 10.63 Amps
    Voltage at MPP (Vmpp): 45.63 Volts
    Efficiency Nominal Power (╖): ≥ 20.7%

View AllClose

Warranty Information

12 Year Product Warranty Performance Guarantee 30 Year Linear Performance Warranty
