Morningstar SunSaver Duo (12 Volt / 25 Amps)

Morningstar’s SunSaver Duo is an advanced PWM two battery controller designed for smaller solar applications, such as RV/ caravans, boats and small homes or cabins. It’s capable of charging two separate and isolated batteries at the same time, such as a “house” battery and an engine battery, based on user selectable priorities.

SunSaver Duo is built on the same platform as Morningstar’s legendary SunSaver, the world’s leading small solar controller for industrial and consumer use. Its long-term track record for high reliability and improved battery charging is well-recognized in the solar industry.

Morningstar’s SunSaver Duo™ is an advanced PWM two battery controller for RV’s, caravans, boats and cottages. This product will charge two separate and isolated batteries at the same time, such as a “house” and an engine battery, based on user selectable priorities. The SunSaver Duo employs Morningstar’s legendary SunSaver controller technology, whose long-term track record for high reliability and improved battery charging is well-recognized in the solar industry.

An optional backlit remote meter can be purchased with this controller, and mounted in or on a wall, to display digital and pictorial status information about the solar power system. The SunSaver Duo is epoxy encapsulated for environmental protection, is user adjustable via DIP switch or connection to a personal computer, and has an optional remote temperature sensor.

“Love it…it was worth the extra money over other brands that seemed to be of lesser quality”

Features

Two Battery Charging

Solar charge current is shared between the two batteries based on a user selectable priority. When one battery is fully charged, all of the charge current flows to the other battery.

Information Display
The remote meter and LED’s on the SunSaver Duo display system status data and any system errors. Custom icons and back lighting make the meter easy to read and understand.

User Adjustable
Easily set parameters with on-board DIP switches or further customize with a PC using Morningstar MSView software.

Lower Cost
Two-battery charging eliminates the added cost of two separate solar chargers and the need for isolation between the batteries.

Easy to Install
The controller is installed near the batteries using the clearly labeled large wire terminals. The remote meter may be mounted in the wall or on the wall using the included frame. Also includes the meter wiring with RJ-11 connector.

Longer Battery Life
Four stage series PWM pulse charging and temperature compensation increases the useful life of the batteries.

Extensive Electronic Protections
The controller is designed to resist damage caused by wiring mistakes during installation. There are no fuses to replace, and the controller will automatically re-set after a wiring mishap.

Highly Reliable
Epoxy encapsulation protects the controller against dust and high humidity. Efficient electronics and a conservative thermal design allow the controller to operate reliably at high temperatures. Advanced thermal design means no cooling fans are needed, which eliminates moving parts, improves long-term reliability, and increases efficiency.
