Generac, PV Link, APKE00010, DC Optimizer, 2500W, MC4 In/MC4 Out

Generac APKE00010 PV Link Substring Optimizer, Compatible with PWRcell Inverters and SnapRS Disconnect Switches, MC4, Max 420Voc
The APKE00010 PV Link from Generac provides substring level optimization to overcome shading and challenging roof lines for all connected modules. Designed to manage up to 2500 watts, PV Link is the simple solar optimizer for quick installation and long-lasting performance.

APKE00010 PV Link Substring Optimizers must be connected to a Generac PWRcell Inverter. Each PV Link optimizer allows up to 9 modules with a total substring voltage of 200 - 420Voc. Up to 3 PV Links are allowed on each PWRcell channel, with up to 6 per inverter.

2017/2020 NEC Rapid Shutdown
All systems are NEC 2017/202 compliant when SnapRS Rapid Shutdown Disconnect Switches are connected to to the negative (-) lead of each PV module.

PLEASE NOTE: Generac PWRcell Installer Certification is required for installation, commissioning and warranty service.

Features

• Fast, simple installation
• Lower failure risk than module-level optimizers
• Quick connections with MC4 connectors
• Exports up to 2500W
• Compatible with PWRcell Inverters
• Cost-effective solution for high-performance PV
• Ground-fault protection
