Discover 42-48-6650 7.4kWh AES Lithium-Ion Battery
- SKU:
- ALG-040-12000
- SHIPPING:
- Estimated Arrival: 5-10 business days
Description
Discover, 7.4kWh, 51.2VDC AES Lithium Ion Battery, Xanbus, 42-48-6650
Discover Advanced Energy (AES) batteries allow for equipment design and functionality improvements and deliver productivity gains through enhanced cycling, charge time and weight reductions in stationary and mobile applications. Dramatic improvements in cycle life and charge efficiency combined
with zero maintenance requirements provide the end user with significant cost of ownership savings.
Features
- Efficient & Fast Charging - Discover AES batteries are 15% more efficient than lead acid batteries, allowing for reduced charge times and greater utilization of renewable energy sources. Discover >95% of their capacity at high and stable voltages, increasing equipment performance and reducing motor fatigue.
- Partial State of Charge (SOC) & Weight Efficient - Discover AES batteries will never suffer negative effects from partial SOC. Systems are 1/3 the weight of their lead acid battery equivalent.
- Battery Management System & Renewable System Ready - Integrated Battery Management System to prevent abuse outside of current, voltage and temperature limits. Xanbus commonport provides plug and play integration with SE Conext XW+, SW, SCP, ComBox and Solar Charge Controllers.
Specifications
-
Manufacturer: Discover Battery
Product Line: AES Lithium Ion
Model ID: 42-48-6650 -
Mechanical Data
Technology: Lithium Ion Battery
Dimensions: 18.50 x 13.70 x 14.70 inches
Weight: 192.00 lbs
Terminal: M8
Terminal Torque: 9 Nm +/-3 | 6.64ft-lb
IP Rating: IP 55
Product Certifications: IEC 6133, UL2271, UL1973, UN 38.3
Shipping Classification: UN 3480, Class 9 (Lithium Ion Batteries)
Cell Chemistry: LiFePO4
Cell Modules: 16S 26P
Cell Temperature: 0°C/45°C
Discharge Temperature: -20°C/50°C
Storage Temperature: -20°C/45°C
Self-Discharge 25°C: < 3% per Month (Battery Off) -
Electrical Data
Nominal Voltage: 51.20 Volts
Charge Voltage: 54.40 Volts
Maximum Voltage: 58.40 Volts
Minimum Voltage: 44.80 Volts
Nominal Capacity (1C): 130 Ah
Nominal Energy (1C): 7390 Wh
Maximum Continuous Current: 130 Amps
Peak Current: 600 A for 3 Seconds
Constant Power - Minutes of Discharge
500 W: 799 Minutes
1000 W: 399 Minutes
2000 W: 200 Minutes
3000 W: 133 Minutes
Constant Current - Minutes of Discharge
@10A: 780 Minutes
@25A: 312 Minutes
@50A: 156 Minutes
@100A: 78 Minutes
