Description
- Unprecedented Solar: Max. 3,200W solar input with dual 11-165V MPPT controllers.
- Gas Generator Charging: Compatible with 240V gas generators (6,000W bypass) for extended power outages.
- Expandable Capacity: Starts at 3.84kWh, expandable up to 26.9kWh for increased energy storage.
- Dual-Voltage AC Output: 120V & 240V, 6,000W AC output to power home appliances; expandable up to 12,000W.
- Remote Monitoring & Control: Monitor and manage power settings via the Anker app with Wi-Fi/Bluetooth.
- Long-lasting Performance: 5-year warranty, with an lifespan of 10+ years using EV-grade LFP batteries.
- EV & RV Charging: Powers EVs and RVs directly through NEMA TT-30P or L14-30 ports.
Features
Up To Massive 3,200W Solar
2 ×165VDC MPPT Input
Recharge with Generator
240V/6000W Bypass
*Anker SOLIX Generator Adapter required and only support single F3800 Plus unit.
6,000 - 12,000W
Whole-Home Backup
120V/240V
Dual-Voltage Output
Built-in NEMA L14-30 Port
Up to 53.8kWh
Max Expandable for Weeks of Power
4 Ways to Recharge
1. 3,300W for single unit, 6,000W when working with 2 or more expansion batteries
2. Working with expansion battery
Storm Guard
Automatic Backup Before Severe Weather
Note: Home Power Panel required.
Directly Charges EVs
Directly Powers RVs
Transfer Switch and Inlet Box Connection
Local Energy Saver Reduces Bills
$5,000+ per Year
Note: Home Power Panel required.
5-Year Warranty,
10-Year LifeSpan
Specifications
-
Manufacturer: Anker
Product Line: Portable Power Solution
Model ID: B1790112Q
Capacity: 3,840Wh
Battery Chemistry: LFP, 3,000+ cycles
Expandable Capacity: Up to 6 × Expansion Batteries (3.84kWh each)
AC Input: 120V~ 15A Max (< 3hrs) / 12A Max (continuous), 60Hz, L+N+PE
AC Input Power (Charging): 1800W Max
AC Input Power (Bypass Mode): 1440W Max
Solar Panel Input: 11-165V ⎓ 17A Max (1600W Max Each)
Anker SOLIX Generator Port: 60V Max, 120A Max
Car Charger Output: 12V ⎓ 10A
HPP & Generator Adapter Port: 6000W Max (AC Input), 6000W Max (AC Output), 120V/240V, L1+L2+N+PE
AC Output Power (Total): 6000W Max
AC Output: 120V~ 20A Max, 60Hz, 2400W Max
AC Output (NEMA L14-30R): 120V/240V~ 25A Max, 60Hz, 6000W Max
USB-A Output: 5V ⎓ 2.4A (12W Max Per Port)
USB-C Output: 5V ⎓ 3A / 9V ⎓ 3A / 15V ⎓ 3A / 20V ⎓ 3A / 20V ⎓ 5A (100W Max Per Port)
Length × Width × Height 27.6×15.3×15.6 in (Including wheels)
Net Weight: 136.7 lb
Warranty: 5-year warranty
BP3800 Expansion Battery
Capacity: 3,840Wh
Weight 72.8 lb
