Enphase

Enphase EN-QD-12-13-120 QD Cable (4x12AWG) (Portrait) 60-72 Cell

SKU:
EN-QD-12-13-120
$3,571.99

Description

QD cable (4x12AWG) 60-72 cell · Connector spacing is 1.7m (5.6ft). · 1.3m (4.3ft) max spacing between microinverters. ·120 4-pin male connectors plug directly into the IQ8 Commercial Microinverters. · 19 additional center taps spaced every 6 connectors. Centre tap connectors spaced at half-spacing to maintain connector spacing.


The Enphase QD Cable and accessories are integral parts of the IQ8 Commercial Microinverter based PV system for grid-tied, three-phase 208 V PV applications.

The QD Cable works with the Enphase IQ8Commercial Microinverter and provides self-phase balancing and neutral sensing for phase loss protection.

Features

Reliable

  • Neutral sensing for phase loss protection
  • Locking-type connectors
  • Rated for outdoor, wet environments, sunlight resistance, and oil resistance

Easy

  • Self-phase balancing
  • Lightweight and simple for fast installation
  • Modularly expandable
  • Reduction in balance-of-system costs and installation time
  • Phase ID marked on QD Cable connectors for easy identification (C1: L1-L2, C2: L2-L3, and C3: L3-L1 sequentially)
  • Separate center feeding connector in all AC branch circuit cabling SKUs for maintaining <1% voltage rise with easy plug-and-play installations

Field Wireable QD Connectors

  • Easily connect QD Cables on the roof without complex wiring
  • Available as male and female connector types
  • UL Listed

Specifications

Manufacturer: Enphase Energy
Product Line: Accessories
Model ID: EN-QD-12-13-120

Available now at SolarTown – trusted distributor.

INFO & GUIDE

pdf.pngDownload EN-QD-12-13-120 Datasheet
